Waveshare ESP32-GEEK Development Board, Based On ESP32-S3R2 Controller Chip, With 1.14inch 65K Color LCD, Supports WiFi & Bluetooth LE

Click here to see why SmartElex is different!

The Waveshare ESP32-GEEK Development Board is a versatile platform designed for IoT (Internet of Things) and embedded projects. Powered by the ESP32-S3R2 controller chip, it offers advanced processing capabilities and features.

One standout feature is the integrated 1.14-inch 65K color LCD, providing a vibrant and interactive display for user interfaces and data visualization. This allows developers to create visually appealing applications without the need for additional display modules.

With built-in support for WiFi and Bluetooth Low Energy (LE), the ESP32-GEEK enables seamless connectivity to local networks and wireless peripherals, making it ideal for IoT applications requiring communication with other devices or cloud services.

Features:

1. Adopts ESP32-S3R2 chip with Xtensa? 32-bit LX7 dual-core processor, capable of running at 240 MHz
2. Built-in 512KB SRAM, 384KB ROM, 2MB of on-chip PSRAM, and onboard 16MB Flash memory
3. Onboard 1.14inch 240?135 pixels 65K color IPS LCDIntegrated 2.4GHz WiFi and Bluetooth LE wireless communication
4. Onboard 3PIN UART port, 3PIN GPIO header and 4PIN I2C port
5. Equipped with plastic case and cables
6. Provides online open-source demos and resources, more convenient for learning and development.

Package Includes:

1 x Waveshare ESP32-GEEK Development Board, Based On ESP32-S3R2 Controller Chip, With 1.14inch 65K Color LCD, Supports WiFi & Bluetooth LE
