TOF (Time Of Flight) Laser Range Sensor (B), UART / I2C Bus, Long Range

The TOF Laser Range Sensor (B) is a TOF-based (time of flight) laser ranging sensor with an embedded MCU and ranging algorithm, which is capable of offering up to 15m measuring range, 2% accuracy, and 1mm resolution. It supports UART or I2C communication bus, features a longer measuring distance and higher light interference resistance capability due to its ultra-narrow FOV, suitable for either indoor or outdoor conditions.
This sensor can be widely used in applications like common distance measuring, robot obstacle avoidance/route planning, as well as drone altitude setting/ceiling detection, and more

Features:

1. Long Range Zone: 15M
2. Short Blind Zone: 1ocm
3. Refresh Rate: 15Hz
4. Field of View: 1 ~ 2
5. Interfaces: UART , I2C

Package Includes:

1 x TOF (Time Of Flight) Laser Range Sensor (B)
