Waveshare RP2350 Microcontroller Development Board, With 1.69inch Touch LCD, Rounded Corners, Dual-core & Dual-architecture Design, Accelerometer And Gyroscope Sensor

Waveshare RP2350 Microcontroller Development Board is a low-cost, high-performance MCU board designed by Waveshare. Tiny size with onboard 1.69inch capacitive touch display, Li-ion battery recharge manager, 6-axis sensor (3-axis accelerometer and 3-axis gyroscope), RTC chip, buzzer, and so on, which makes it easy for you to develop and integrate it into products quickly.

Features:

1. RP2350 microcontroller chip designed by Raspberry Pi in the United Kingdom
2. Adopts unique dual-core and dual-architecture design: dual-core Arm Cortex-M33 processor and dual-core Hazard3 RISC-V processor,
3. flexible clock running up to 150 MHz
4. 520KB of SRAM, and 16MB of onboard Flash memory
5. Type-C connector, keeps it up to date, easier to use
6. Onboard 1.69inch capacitive touch display, 240280 resolution, 65K color
7. Lithium battery recharge/discharge header, suitable for mobile devices
8. Onboard RTC chip and RTC battery header for timing and scheduling functions
9. Onboard buzzer for sound-producing peripheral
10. USB 1.1 with device and host support
11. Low-power sleep and dormant modes
12. Drag-and-drop programming using mass storage over USB
13. Accurate clock and timer on-chip
14. Temperature sensor

Package Includes:

1 x RP2350-Touch-LCD-1.69
