NanoPC-T6 4GB RAM-32GB eMMC Bare Board No Accessories

The NanoPC-T6 LTS is a high-performance, open-source platform for edge computing, designed and developed by the FriendlyElec team. Powered by Rockchips RK3588 processor, it comes with 4GB LPDDR4x RAM and an optional 32GB eMMC flash. The board features dual 2.5G Ethernet ports and supports multiple operating systems including OpenMediaVault, FriendlyWit, Android, Android TV, Debian, and Ubuntu. With GPU and VPU acceleration, it is capable of handling demanding multimedia and AI workloads. Measuring just 110 x 80 mm, the compact T6 LTS also offers an optional CNC metal case for added durability.

Equipped with two HDMI Out ports and one HDMI In port, the T6 LTS can play 8K@60P H.265/VP9 and 8K@30P H.264 video streams, as well as record 4K@60P H.265 streams. Expansion options include an M.2 B-Key slot for NVMe SSDs and an M.2 E-Key slot for WiFi modules. Additional connectivity features include one USB 3.0 port, two USB 2.0 ports, and a full-featured USB-C port powered by DC-12V. With its rich hardware resources and flexible design, the NanoPC-T6 LTS is an excellent choice for enterprise customers developing machine vision systems with multiple Ethernet ports, as well as for embedded system enthusiasts building innovative prototype solutions.

Features:

1. Rockchip RK3588 Quad-core ARM A76 & Quad-core A55
2. 64-bit 4GB RAM LPDDR4X@2133MHZ
3. 32 GB eMMC
4. Dual 2.5G Ethernet Ports
5. HDMI In Up to 4K@60P
6. HDMI Out Up to 8K@60P
7. FriendlyWrt 23.05 w/ Kernel 5.10
8. UbuntuCore/Desktop w/ GPU&VPU accelerated
9. Android 12 TV
10. Android 12 Tablet
11. USB-C Support DP
12. up to 4K@60P
13. M.2 WiFi & SSD PCle Extension
14. PCB: 8 Layer
15. Weight: 91.5g(without Case).
16. Dimension: 110x80x1.6mm

Package Includes:

1 x NanoPC-T6 4GB RAM-32GB eMMC Bare Board No Accessories
