Gremsy VIO G1

The Gremsy VIO G1 is an advanced, lightweight EO/IR payload designed to deliver exceptional imaging performance for various industrial applications. Equipped with a high-resolution 4K zoom sensor and a 640512 thermal camera, the VIO G1 provides both detailed optical and accurate thermal imaging.

It also features a 2400m laser rangefinder for precise distance measurements, making it ideal for tasks like surveillance, inspection, and search-and-rescue operations. Its compact and lightweight design ensures easy integration with drones, offering reliable performance in diverse environments and lighting conditions.

Features:

1. 4K Zoom Sensor: Delivers high-resolution optical imagery for detailed visual inspection.
2. 640512 Radiometric Thermal Camera: Provides accurate thermal imaging with precise temperature measurement.
3. 2400m Laser Rangefinder: Integrated laser for accurate distance measurement up to 2400 meters.
4. Lightweight Design: Compact and easy to integrate into various drone platforms.
5. Versatile Applications: Suitable for industrial tasks such as surveillance, inspection, and search-and-rescue operations.
6. EO/IR Capabilities: Dual Electro-Optical and Infrared imaging for optimal performance in any lighting condition.
7. Supported Drone Platforms : Pixhawk/CubePilot/Skynode
8. EO camera : Powered by Sony Block 4K Camera
9. IR camera : Vio G1: Powered by Thermal Core 640 R
10. Laser Rangefinder Range : 0 3000 (1Hz) , 0 1250 (10Hz)
11. Payload Control Method UART/Ethernet, SBUS (updating with expansion board)
12. Supported Controllers Ground Station/Remote with QGroundControl app , Gremsy Payload Assistant App

Package Includes:

1 x Vio Payload
1 x Vio Damping
1 x Vio/Zio/Mio Quick Release
1 x USB Type A to USB Type C
1 x Micro USB cable
1 x Vio CTRL Cable
2 x Power Cable
1 x Micro SD Card SDXC I, 128GB
4 x M2 x 4 ISO 4762
4 x M3 x 6 ISO 4762
4 x M3 x 6 DIN 7991
1 x Allen Key 1.5mm
1 x Allen Key 2.0mm
1 x Allen Key 2.5mm
