SpeedyBee Bee35 3.5 inch Frame

The O3 Air Unit Protective Case is meticulously designed for optimal protection and performance enhancement. Crafted with custom-made aluminum alloy and silicone shock absorption, it ensures effective protection against damage and eliminates the jelly effect. With features like heat dissipation, versatile stack compatibility, and convenient connectivity options, it offers durability, ease of installation, and seamless integration with various drone components.

Note: Refer to the User Manual in the ATTACHMENTS section for more info.

Features:

1. A custom aluminum alloy head safeguards the O3 Air Unit.
2. Silicone shock absorption eliminates the jelly effect for smoother footage.
3. Custom-designed bottom aluminum alloy ensures effective heat dissipation.
4. Compatible with 20x20mm, 25x25mm, and 30.530.5mm stacks.
5. Dual binding designs for both horizontal and vertical battery support enhance durability.
6. Supports Type-C and micro interfaces for easy connection to flight
7. Camera Mounting Distance: 19/20mm
8. ESC/Motor Mounting Height: 24mm
9. Flight Stack Mounting Holes: 20*20/25.5*25.5/30.5*30.5mm
10. Video Transmitter Mounting Holes: 20*20/25.5*25.5
11. Recommended Motor: 1806/2004/2006
12. Recommended KV: 4S/2500-3500KV, 65/1800-2300KV

Package Includes:

1 x SpeedyBee Bee35 3.5 inch Frame
